Outdoor Lighting

Model:

Street Lighting

Applications:

Street Lighting & Factory Lighting

Outdoor Series  (Steel Paint, Aluminium Anti-UV Coating, Aluminium Frame)
The only light sources in the dark, provides sufficient lighting for streets and factories. Increasing the safty in general on road, reduces the CO2 emission amount and  saves upto 50% of energy consumption.

Efficiency(W)      ：  60~150
Color(K)                     ：  2800~5700
Optical Lens         ：  95∘132∘180∘5mm
Made in Taiwan



Replacement Optical Lens
Several project angle of optical lens can be choosed  for usage in different environments.
Condensation Lens(56°)、Diffusion Lens(95°)、Street light Lens(132°)、Expansion Lens(180°)

Optical lens provides different lighting shape which applies to  several  usages.

Luminous Flux & Distribution Chart (Based on 100W Lighting Source)

Hight (m)     Center Luminous Flux (Lux)
    6                  351
    8                  197
   10                 126

 Hight (m)     Center Luminous Flux (Lux)
    6                      173
    8                      97
   10                     62		 Hight (m)     Center Luminous Flux (Lux)
    6                      116
    8                      65
   10                     42
